Troubleshoot: Unleveled Bot DrawingUpdated a day ago

If your Bot’s drawings appear tilted or uneven—like the marker touches one side of the paper but not the other—use this guide to resolve the issue.

Primary Causes & Fixes

1. Pen Is Dry or Worn Out

   • The marker might no longer produce consistent ink. Try replacing it with a new one and test again.

2. Table Not Leveled

   • Ensure the surface where the Bot is drawing is flat and stable.

   • Use a spirit level to verify.

3. Bot Not Properly Seated

   • Remove the Bot from the paper holder.

   • Clean the paper holder base and the Bot’s bottom to remove any debris.

   • Reseat the Bot firmly and ensure it sits flush with the surface.

4. Bot Firmware or Calibration Issue

   • May require a firmware update or factory reset (see below).

At an Event? Quick Workaround

If you're on-site and can't reset the Bot immediately:

• Use Z+ Calibration Compensation:

  1. Perform normal pen calibration using Z+.

  2. Once the pen touches the paper, press Z+ +1.0 four times (or more if needed).

  3. This pushes the pen slightly deeper, helping compensate for minor unleveled surfaces.

  4. This often fixes the issue until a full recalibration/reset can be done.

Factory Reset + Home Recalibration Steps

1. Disconnect Bot from power and close the software.

2. Reconnect Bot to power and reopen the software.

3. Open the Terminal in the software:

   • Type: M502 → Send (Factory Reset)

   • Type: M500 → Send (Save Settings)

4. Type: M18 → Send (Disengages motors)

5. Manually push the arm back and up, ensuring it is centered.

6. Type: M889 → Send (Home Position Save)

7. Type: M1112 → Send (Return arm to Home automatically)

8. Recalibrate pen height.

9. Test the drawing.

📹 Video tutorial available here:

Still Not Resolved? Try Rotrics Studio Recalibration

1. Download and install Rotrics Studio.

2. Connect the Bot via USB.

3. Check for firmware updates and apply if available.

4. Recalibrate and test the Bot.

📹 Video tutorial available here:
